Automatic wire cutting stripping machine

Short Description:

Product Model: XCX-10²


Product Detail

Product Tags

● PRODUCT INTRODUCTION

size 420*380*270(MM) cutting length 1-9999MM
Package dimensions 500*460*360(MM) peeling length Line head 25MM Line tail 25MM
net weight 27KG Cut the core 0.1-10MM² (BVR)
Gross weight 32KG cutting tolerance 0.002*L·MM
Conduit Specifications 15*100 (outer diameter 4, 6, 8, 9, 10) MM drive mode four-wheel drive
Blade material high speed steel pulse equivalent No error within 1M
motor stepper motor Line pressure adjustment manual adjustment
drive segment driven Productivity 2000-5000Pcs/hour
Function Long line, short line, flat line, sheath Multi-segment 15 paragraphs
price   MOQ 2

Remarks function: automatic advance and retreat line, one-key adjustment of tool value, output setting, timing start and stop, manual wheel lift.
