Chengzhou 6 Axis Force sensor dimensional load cell Six-Axis Torque Sensor KWR46 SERIES for Robotics

● Product description

Using aviation alloy, high overload, high rigidity and high sensitivity KWR46 series six-axis force sensor is a small high-precision force sensor, which can measure the force and moment in three orthogonal directions in real time. The sensor is designed based on the principle of strain electrical measurement, and uses six-axis joint calibration technology to improve accuracy. It can be seamlessly connected with various signal acquisition modules to realize communication methods such as RS422, RS485, CAN, USB and industrial Ethernet, and is widely used in medical testing, small industrial robots, automatic measurement, aerospace testing and other fields.

1. Six-axis joint calibration fully suppresses crosstalk
2. Small high-precision six-axis force sensor
